Yeastar - NeoGate TA800 - 8 FXS Analog VoIP Gateway

Product Overview

Featuring 8 FXS ports, the Yeastar NeoGate TA800 connects analog terminals, PBX or key systems to the IP network using FXS connectivity. The NeoGate TA800 multi-port FXS gateway helps to preserve previous investments on legacy telephone systems and reduce communication costs significantly with the true benefits of VoIP.

Yeastar TA800 features 8 FXS ports for analog phones and is designed to meet various demands of IP applications. The powerful features and robust performance simplify the integration of legacy phone system and IP-based system.

Keys Features and Functions

• Fully compliant with SIP and IAX2
• Flexible calling rules
• Reliable fax performance with T.38
• Superb voice compression with industry standard codecs
• Line echo cancellation for 8, 16, 32, 64 or 128 ms echo delays
• User-friendly Web GUI and intuitive operations for easy configuration and management
• Excellent interoperability with a wide range of legacy and IP equipment
• Tested and certified with Elastix, BroadSoft, and others
• LED indicators present system and port status visually
• Comprehensive call log, system logs, hardware logs, and debug logs

Specifications

Ports		8 FXS Ports
Telephony Interfaces		RJ11
LAN		1 10/100Mbps
Protocol		SIP (RFC3261), IAX2
Transport		UDP, TCP, TLS, SRTP
Codec		G.711 (alaw/ulaw), G.722, G.723, G.726, G.729A, GSM, ADPCM
Voice Capability		ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer
DTMF Mode		RFC2833, SIP Info, In-band
Fax		T.38 and Pass-through
QoS		DiffServ, ToS, 802.1 P/Q VLAN tagging
Network		DHCP, DDNS, OpenVPN, PPPoE, Static Route, VLAN
Network Protocol		FTP, TFTP, HTTP, HTTPS, SSH
Management Protocol		RADIUS, TR-069*
Signaling		FXS Loop Start, FXS Kewl Start
Caller ID		BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID
Disconnect Methods		Busy Tone, Polarity Reversal
FXO Connectivity		–
Power		12V, 1A
Dimensions (L × W × H) (mm)		200 × 137 × 25
Operation Range		0°C to 40°C, 32°F to 104°F;
Storage Range		-20°C to 65°C, -4°F to 149°F
Humidity		10-90% non-condensing
Mounting		Desktop, Wall-mount
Compatibility		Interoperable with 3CX, Asterisk, Lync Server, FreePBX and certified with Elastix and BroadSoft
