Supporting Android 13, the Yealink MeetingBar A40 is future-ready, allowing users to access the latest features and updates. It integrates with Microsoft’s MDEP for improved security and streamlined deployment, creating a more secure and efficient setup. The device also connects directly to the Yealink CTP25 control panel, providing a convenient, fast login process that enhances user experience and reduces setup time.
Yealink Meetingbar A40 Technical Specifications
Specifications
- Operating System: Android 13
Camera
- Maximum pixels: 2 x 48MP
- Number of preset positions: 9
- Electronic gimbal
- Field of view (DFOV): 120°, VFOV: 54°, HFOV: 110°
- Depth of field: 1-5 meters
- Digital zoom: 6x
- Maximum resolution: 4K
- Frame rate: 60FPS
- Video output resolution: 4K60fps, 1080P60fps
- Effective focal length: 4.2 mm
- Aperture: F/2.2-F/2.4
- Supports wide dynamic range and 10-bit high dynamic range imaging
- Auto exposure
- White balance options: ATW/auto/manual
- Shutter speed: 10ms-33ms
- Minimum illumination: 0.5 lux (daytime), 0.1 lux (nighttime)
- Signal-to-noise ratio: >63 dB
- Privacy cover: Electric lens cap
- Lens calibration
- Intelligence Features: IntelliFocus, Auto Framing, Speaker Tracking, People Counting, Picture in Picture, Multi-focus Framing, Smart Gallery (Zoom only)
- Number of cameras: 2
Speaker
- Built-in speakers: 2 x 10W
- Maximum sound pressure level: 112dBSPL 10W@0.1m
- Frequency response: 100-16kHz
- Sensitivity: 86dB SPL @ 1W @ 0.5 meter
- Sampling rate: 48kHz
- Sound emission angle: Forward-facing
- Total Harmonic Distortion (THD): <5% at 10W, 1kHz
- Rated impedance: 4 ohms
- Maximum power: 12W
- Rated power: 10W
Microphone
- Built-in 8 MEMS microphone array
- Pickup distance: 6 meters, high-quality pickup at 4 meters
- Signal-to-noise ratio: 72dB
- Maximum sound pressure level: 130dBSPL (whole device), 100dBSPL (individual microphone)
- Dynamic range: 28-100dBSPL
- Sensitivity: -38dBV/pa
- Frequency response: 100-20kHz
- Sampling rate: 48kHz, 32-bit depth
Resolution
- Portrait resolution: up to 4K30fps
- Bandwidth requirement: 10Mbps or more
Content Sharing
- General Mode: Up to 4K15
- Teams: 1080p in meeting, 4K local sharing
- Zoom: 1080p
Communication Standard Protocol
- SIP/H.323 in General Mode
Network Protocol
- Wi-Fi 6: 2.4G & 5G dual-band, 802.11a/b/g/n/ac/ax with 2x2 MIMO
- Bluetooth 5.0
- TCP/IP (IPv4/IPv6), DHCP/static IP
- HTTPS secure web access
Configuration Management
- Automatic configuration via web page/display/AutoP
- Firmware upgrade, factory reset
- Configuration import/export
- System log export
Device Management
- Yealink HTTPS Web Portal, Yealink Device Management Platform, Yealink Management Cloud Service
- Microsoft Device Management Platform (Teams Admin Center/Intune)
- Zoom Device Management
Installation
- Wall mount, TV-Clip Mount, or place on desktop
Ports
- 1x USB2.0 USB-A port
- 1x USB-C port
- 1x Ethernet port
- 1x Yealink VCH port (RJ-45)
- 1x 3.5mm Line-in & Line-out port
- 1x Power port
- 1x Security lock slot
- 1x Reset slot
- 2x HDMI-out
Package
- Contents: MeetingBar A40, VCR11 Remote Control, HDMI cable x2, Network cable x1, TV-Clip Mount x1, Wall Mount x1
Environmental Factor
- Operating humidity: 10 - 95%
- Operating temperature: 0 - 40°C
Dimensions and Weight (W × D × H)
- MeetingBar A40: 650 × 62 × 80 mm
- N.W/CTN: 5.540 kg
