Luxury and Elegant
Designed with an aluminum alloy finish, the i63 combines technology and art. The 5 speed-dial buttons with blue backlight enable users to see clearly even in low light conditions
Strong and Durable
Featuring highly waterproof and dustproof casing with anti-collision grade material, the i63 has great performance in different outdoor environments. The anti-tamper alarm will report to the control center when the cover is unauthorized opened.
Smart and Convenient
The Fanvil i63 allows users to achieve smart access control with RFID/IC cards, indoor switch, remote DTMF and Timed open door. It provides clear video images even in dark with an infrared night-vision camera.
Thoughtful and Helpful
The i63 is able to be integrated with induction loop antenna, providing a better experience for users with hearing impairment.
Linkage with Security System
With rich input and output interfaces, the i63 can be connected with 3rd party devices. It is easy to be integrated with security products in different solutions, reducing investment cost and safeguarding the security of communities.
Remote Access Control with Mobile Phone
Residents can communicate with visitors and easily identify visitors via mobile phone APP. With one-click door opening feature, it saves lots of time and greatly improves management efficiency.
Zero Touch Deployment
Fanvil Device Management System (FDMS) enables users to realize plug-and-play and efficient auto-provisioning online, realizing the remote management and upgrade.
i63 Video Door Phone
- 2 SIP lines
- Video intercom
- IP address announcement in English
- Programmable DSS key
- RS485 port: Support
- Wiegand port: Support
- Switch signal input and output
- Door control in and out
- Line-out for induction loop antenna: Support
- Support TF card
- PoE enabled
- Open the door operation: DTMF, RFID card, indoor switch, Time open door
- RFID cards (support 10,000)
- Door open records (support 200,000)
Device Functions
- Auto-answering
- Programmable DSS keys
- Through button or web page volume adjustment
- Network time synchronization
- Time Plan (task management)
- Dynamic multicast function
- SIP call multicast function
- HTTP API
- Action URL / Active URI
Call Functions
- Call out / answer / reject
- Call waiting
- Intercom, Multicast
- Speed dial
- Anonymous call (Hide caller ID)
Audio
- Narrowband codec: G.711A/U, G.729A/B,iLBC,G.723.1,G.726-32K
- Wideband codec: G.722, Opus
- Full-duplex hands-free speakerphone with AEC
- DTMF: In-band, Out-of-Band (RFC2833/ SIP INFO)
Video
- Sensor: 1/2.9” color CMOS
- Pixels: 2 Mega
- Video coding: H.264
- Motion detection
- Resolution:High intensity IR LEDs for picture lighting during dark hours with internal light sensor
- Main stream 1080P@30fps
- Sub stream VGA@30fps
- Viewing angle:
- Diagonal: 141°
- Horizontal: 120°
- Vertical: 60°
Network
- Physical: 10/100 Mbps Ethernet
- IP mode: IPv4/IPv6/IPv4&IPv6
- IP configuration: Static IP / DHCP / PPPoE
- VPN: L2TP / OpenVPN
- VLAN
Protocols
- SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS
- RTP/RTCP/SRTP
- STUN
- DHCP
- IPv6
- PPPoE
- L2TP
- OpenVPN
- SNTP
- FTP/TFTP
- HTTP/HTTPS
- TR-069
