Milesight MS-S0424-GF - 24X10/100Mbps PoE ports (RJ45) + 2X1000Mbps uplink ports + 2X1000Mbps SFP ports

Tulis review Anda tentang produk ini

Stok: Tersedia

Rp 5.227.000,00

Sinopsis

Key Features



  • Ports (24X10/100Mbps PoE ports + 2X1000Mbps uplink ports and 2xSFP uplink ports)

  • PoE Protocol (IEEE 802.3af and IEEE 802.3at Power over Ethernet (PoE) compliant)

  • Total PoE Power (Power budget of 250W and 30W for all PoE port and single port respectively)

  • Self-adaption Port (RJ45 Port support 10/100Mbps auto MDI/MDIX)

  • Extend Mode (Extend PoE up to 250M on one single cable)

  • Wide Application (Available for wireless AP and network cameras through CAT-5 cable)

  • Surge Protection (Protect the device from lightning surges and other electrical hazards)

  • SFP Uplink Port (Provide more than enough bandwidth and stability for ultra high speed data transferring)

  • Easy to Use (Easy understandable working status, simple and convenient functions with no configuration)

Milesight MS-S0424-GF -  24X10/100Mbps PoE ports (RJ45) + 2X1000Mbps uplink ports + 2X1000Mbps SFP ports

Klik-ganda gambar di atas untuk melihat ukuran aslinya

Perkecil
Pebesar

Gambar Selengkapnya

Detil

Product Spesifications

Ports : 24X10/100Mbps PoE ports (RJ45) + 2X1000Mbps uplink ports + 2X1000Mbps SFP Ports

Standard  : IEEE802.3 10Base-T
                   IEEE802.3i 10Base-T
                   IEEE802.3u 100Base-TX
                   IEEE802.3ab 1000Base-TX
                   IEEE802.3a 1000Base-TX
                   IEEE802.3x

Switching Capacity : 14,8Gbps (non-blocking)

Packet Forwarding Rate @64byte : 6.55Mpps

Packet Forwarding Cache : 4M

MAC : 16K

Power Supply :
Built-in switching power supply
AC 100~240V, 50-60Hz, 5A

PoE Standard : IEEE802.3af/at

Max. PoE Power : Max capacity: 400W
                              Max capacity for single port : 30W

Functional Switch : Port 1~24: 10/100Mbps auto-sensing @100 meters & port 25~26:1000Mbps@100 meters & port 27~28:1000Mbps

Indicator :
Power Indicator: PWR (green)
Network Indicator: Link (yellow)
PoE Working Indicator: PoE (green)

Cooling Fan : 1
Operating Temperature : -20°∼55°C

Storage Temperature : -40°∼75°C

Operating/Storage Humidity : 5%∼90%RH(non-condensing)

Port lightning protection: 4KV 8/20us

Protection level: IP30

Dimensions : 440mm(W)*225mm(D)*44mm(H)

Weight : 4.5kg

Installation Method : Desktop Type, Wall Mounted Type

Warranty : 1 years

* Naming Convention
 E - 10/100Mbps Uplink Port
 G - Gigabit Uplink Port
 L - Extend Mode
  F - Optical Fiber Port(SFP)
