Protocol/Standards

SIP RFC3261, DNS (A record, SRV, NATPR), TCP/IP/UDP, SRTP, RTP/RTCP, RTCP-XR. HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTRI), DHCP, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, IPv4, IPv6

Voice Codecs

• Support for G.711µ/a-law, G.729A/B, G.726, G.722 (wide-band), G.723, iLBC, Oupus, in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, AEC, CNG, PLC, AGC, AJB, Noise Shield

Graphic

• 1.77 inch (128x160) color LCD, 1 * Dual color MWI

Peripherals

• 2 soft keys, navigation keys, confirm key, dial key, hang up key, speaker key, programmable key, quick access and mute key, backlight DTMF keyboard, volume keys, Push-to-Talk key, accelerometer, proximity sensor

Push-to-talk

• Customizable function button for alarm and paging

Bluetooth

• Yes, Integrated

Auxiliary Ports and Push-to-Talk

• 3.5mm headphone interface (CTIA cable sequence), Type-C charging interface (support fast charging)
• Customizable function button for alarm and paging

WI-FI

• Yes, integrated dual-band Wi-Fi 6 802.11 a/b/g/n/ac/ax (2.4GHz & 5GHz). 802.11k/r/v Supported
• WiFi Encryption : Support WEP, WPA, WPA2, WPA3 (personal)

Security

• Ordinary user and administrator level passwords based on SHA-256 and SHA-256 sess authentication, SIP authentication algorithms based on SHA-256, SHA-256 sess, SHA-512-256, SHA-512-256 sess, MD5 sess. AES security profile, SRTP, TLS call encryption, 802.1x media access control.

HD Audio

• The handset is broadband audio, supporting HAC and dual Mic

QoS

• Supports Layer 3 QoS (Tos, DiffServ, MPLS, DSCP)

Multi-language

• Simplified Chinese, Traditional Chinese, English, Arabic, Catalan, Czech, German, Greek, Spanish, French, Hebrew, Croatian, Magyar, Italian, Japanese, Korean, Latvian, Dutch, Polish, Portuguese, Russian, Swedish, Slovenian, Slovak, Turkish, Ukrainian

Upgrade/ Provisioning

• Firmware upgrade via FTP / FTPS / TFTP / HTTP / HTTPS, mass provisioning using GDMS/TR069 or AES encrypted XML configuration file

Power and Green Energy Efficiency

• Universal Power Adapter included Input: 100-240VAC: Output +5VDC, 1A (5W), 1500mAH Li-ion battery, 120h standby time and 6h talk time (laboratory data)

Physical

• Headset dimensions: 135.00 x 49.00 x 15.5mm
• Charger cradle dimensions: 85.00 x 85.00 x 25.8mm
• Handset weight: 82g
• Handset package weight (not including QIG) weight: 389g

Package Contents

• WP816 phone, Type-C power adapter, charger base, belt clip, 1 lithium-ion battery, M3 screw, wall bracket, quick installation guide

Wall Installation

• Base supports wall installation

Compliance

• FCC, CE, RCM, EAC
