Grandstream GWN7816P - Enterprise Layer 3 PoE Managed Network Switch

Grandstream GWN7813 Technical Specifications

Network Protocol

• IPv4
• IPv6
• IEEE 802.3
• IEEE 802.3i
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3z
• IEEE 802.3ae
• IEEE 802.3x
• IEEE 802.3af/at/bt
• IEEE 802.1p
• IEEE 802.1Q
• IEEE 802.1w
• IEEE 802.1d
• IEEE 802.1s
• IEEE 802.3az
• IEEE 802.3ad
• IEEE 802.3AB
• IEEE 802.1p
• IEEE 802.1D
• IEEE 802.1x

Gigabit Ethernet Ports

• 48

Gigabit SFP+ Ports

• 6

Note: Supports DAC cable, and must be ≤ 5m

Maximum no. of Supported Modules

• SM-10G: 6
• MM-10G: 6
• RJ45-10G: 3

Note: RJ45-10G modules must be interval inserted

Console

• 1

# of PoE Ports

• 48

PSU

• 1 PSU of 920W by default

Maximum Output Power Per PoE Port

• 60W(1-8,PoE++)
• 30W(9-48)

Surge Protection

• ± 4KV CM and ± 2KV DM for power
• ± 4KV CM for network ports

ESD

• ± 12KV for contact discharge

Auxiliary Ports

• 1x Reset Pinhole

Forwarding Mode

• Store-and-forward

Total non-blocking throughput

• 108Gbps

Switching Capability

• 216Gbps

Forwarding Rate

• 160.704Mpps

Packet Buffer

• 16MB

Network Latency

• <4µs

Switching

• 32K MAC addresses, including static, dynamic and filtering MAC address
• 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
• VLAN virtual interface
• GVRP (pending)
• 27 Link Aggregation
• Spanning tree, 64 instances for STP/RSTP/MSTP/PVST(+)

Routing

• Static routing
• Dynamic routing, including RIP, RIPng, OSPF and OSPFv3
• Policy routing (pending)

Multicast

• IGMP Snooping with IGMPv2 and IGMPv3
• MLD Snooping with MLDv1 and MLDv2
• MVR (pending)

QoS/ACL

• Port priority
• Priority mapping
• Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ
• Traffic shaping
• Rate limit
• 4K ACL for Ethernet, IPv4 and IPv6

DHCP

• DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43

Maintenance

• CPU and memory monitoring
• SNMP
• RMON
• LLDP&LLDP-MED
• Backup and restore
• Syslog
• Diagnostics including Ping, Traceroute, port mirroring, UDLD (TBD) and copper test

Security

• User hierarchical management and password protection, HTTPS, SSH, Telnet
• 802.1X authentication
• AAA authentication including RADIUS, TACACS+
• Storm control
• Port isolation, port security, sticky MAC
• Filtering MAC address
• IP source guard, DoS attack prevention, ARP inspection
• DHCP Snooping
• Loop protection including BPDU protection, root protection (pending) and loopback protection (pending)
• Kensington Security Slot (Kensington Lock) support

Mounting

• Desktop, Wall-Mount, or Rail-Mount (rack-mounting kits included)

System LEDs

• 1x tri-color LED for device tracking and status indication
• 2x bi-color LEDs for per power supply PSU1/2
• 54x green-color LEDs for data transferring

Fan

• 4

Environmental

• Operation: 0°C to 45°C, humidity 10-90% RH (Non-condensing)
• Storage: -10°C to 60°C, humidity: 10% to 90% RH (Non-condensing)

Dimensions

• 440mm(L)x380mm(W)x44mm(H)

Unit Weight

• 6 Kg

Package Content

• 1x Switch
• 1x 1.2m (10A) AC Cable
• 1x 25cm Ground Cable
• 4x Rubber Footpads
• 1x Power Cord Anti-Trip
• 2x Front Rack-Mounting Kits

• 2x Rear Rack-Mounting Kits
• 2x Rear Slideways
• 16x Screws (KM 3*6)
• 1x Quick Installation Guide

Compliance

• FCC
• CE
• RCM
• IC
• UKCA
