Fanvil CA400 All-in-one Wireless Conference Solution

Fanvil CA400 Technical Specifications

MS10

• Max. Screen Share Output Resolution: 1920x1080 @30FPS
• Microphone
  • Built-in: 8 MEMS Microphones for 360° pickup
  • Pick-up Range: 4M
  • Signal to Noise Ratio（SNR）: 64.5dB(A)
  • Sensitivity: -26dBFS@1kHz(0dB=1V/Pa)
  • Acoustic Overload Point: 119dB SPL <10%@1kHz
  • Frequency: 20Hz-10KHz
  • Duplex
  • Beamforming
  • Automatic Noise Suppression
  • Acoustic Echo Cancellation
  • Automatic Gain Control
• Speaker
  • Speaker: 4Ω 3W
  • Speaker Size: 50mm
  • Sensitivity: 1KHz 85 dB ± 3dB @1m, 3W
  • Signal to Noise Ratio (SNR): 50dB
  • Frequency Range: 200Hz-10KHz MAX 5%
  • Max. Sound Pressure Level: 85dB SPL@1m @3W
  • Background Noise: <30dB
  • Total harmonic Distortion: 200Hz-10KHz MAX 5%

RC10

• WI-FI
  • Protocol: 802.11 a/n/ac
  • Wireless Transmission Protocol: Quick UDP Internet Connections
  • Transmission Distance: Up to 10M
  • Frequency bands and the maximum transmitted power (For EU):
    • 5180-5320MHz (Wi-Fi 5GHz), Max 20dBm
    • 5500-5700MHz (Wi-Fi 5GHz), Max 20dBm
• Camera Streaming
  • Max. Output Resolution: 1920x1080 @30fps
  • Support Camera Type: UVC camera
  • Format Supported: H.264

CM70

• USB Camera
  • Sensor Type: IMX 415(1/2.8") 3840*2160
  • Output Resolution: MJPEG/ H264/ H265/YUV/ NV1230P (YUV and NV12 don‘t support 4K and 2K resolutions)
  • FOV: DFOV 118.5°/HFOV 109.9°/VFOV74.6°
  • Auto Framing: Auto
  • F/No: F2.5
  • Zooming：5x digital zoom
  • Maximum Resolution: USB3.0:3840*2160p30/ USB2.0:1920*1080 p30
  • Security Protection: Manual Camera LensCover
• Microphone
  • Microphone Type: 2 Electret Microphones
  • Pick-up Range: 4m
  • Signal to Noise Ratio: 94dB SPL@1KHz 65dB(A)
  • Microphone Sensitivity: 94dB SPL@1KHz- 30±2dBFS
  • Duplex
  • Automatic Noise Suppression
  • Automatic Gain Control
• Package
  • USB Camera: CM70
  • Speakerphone: MS10
  • Receiver: RC10
  • Remote Control
  • Power adapter: 5V/2A
  • 1.5m HDMI Cable
  • 20cm USB-C to HDMI & USB-A/C Adapter
  • 40cm USB Extension Cable
  • 1.8M Type C-A USB Cable
  • Quick start guide
  • Gift box dimension: 242*184*108.5mm
  • Outer CTN dimension: 563*257*401mm(10PCS)
  • N.W/CTN: 14.92 kg
  • G.W/CTN: 15.92 kg

Product Dimensions

• USB Camera: 80x75x53mm / 3.15x2.95x2.09"
• Speakerphone: 180x81x32mm / 7.09x3.19x1.26"
• Receiver: 102x45x20mm / 4.02x1.77x0.79"

Product Weight

• USB Camera: 210g / 7.4oz
• Speakerphone: 385g / 13.58oz
• Receiver: 70g / 2.47oz

Working Temperature and Humidity

• Working Temperature: 0℃～40℃
• Working Humidity: 10%～90%RH

I/O Interface

• USB Camera: Type-C x1
• Speakerphone: Type-C PD + DP ALT
• Receiver: HDMI x1; Type-C PD; USBA3.0 x1

Operating System

• Win 10/11
• Mac 10.8 and Later
