Fanvil A212 - Wall-mounted SIP Speaker

Fanvil A212 - Technical Specifications

Generic

• 2 SIP lines
• Wall-mounted installation, rotary support installation (optional)
• Main speaker 8Ω15W can be connected to external 8Ω15W passive sub-speaker
• Built-in microphone, support monitoring, self-test, intercom application
• Support HD voice, using G.722 and Opus encoding
• Support lossless sound quality broadcasting, MP3 and Wav encoding
• Support 20 multicast partitions
• Built-in 24MB audio file storage space, support scheduled task broadcast
• Customize audio files for emergency notification and alarm
• 3 short circuit input detection, 1 short-circuit output, linkage security alarm device
• Support external IP camera video linkage
• Support Web remote adjustment volume
• Support PoE/PoE+ power supply or DC24V/2A power supply
• adaptive 10/100 Mbps network port

Device Functions

• Default auto answer (Auto-answering
• Network time synchronization
• Remote volume adjustment
• Dynamic multicast function
• Action URL / Active URI

Audio

• Audio codecs: G.711A/U, G.729A/B, iLBC, G.723, G.726-32K,G.722, Opus
• DTMF: In-band, out-of-band (RFC2833/SIP INFO)
• Speaker:
  • 5" coaxial treble
  • Frequency response : 100-20KHz
  • Sensitivity: 88dB±3dB 1M/1W
  • Impedance:8Ω
  • MAX SPL: 105dB
  • Speaker Power: PoE/8W, PoE+/15W, DC 24V/2A：15W (support external 8Ω15W sub speaker)
• Mic:
  • Omni-Directional Microphone
  • Sensitivity:-38±3dB, impedance 2.2k ohm, bias voltage 2V

Network

• 10/100 Mbps
• Network mode:IPv4/IPv6/IPv4&IPv6
• IP Setting:Static IP / DHCP / PPPoE
• VPN: L2TP / OpenVPN
• VLAN
• LLDP
• QoS

Protocols

• SIP2.0 over UDP/TCP/TLS
• RTP/RTCP/SRTP
• STUN
• DHCP
• IPv6
• PPPoE
• L2TP
• OpenVPN
• SNTP
• FTP/TFTP
• HTTP/HTTPS
• TR-069

Deployment & Management

• Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIPPnP/TR-069
• Web management portal
• Web-based Packet-dump
• Configuration export / import
• Firmware upgrade
• Syslog

Physical Specifications

• DC 24V/2A port×1 ; 2 pin terminal socket

• RJ45 port x1: connect the internet or LAN, Support PoE power supply (IEEE 802.3at, class 4)
• SPK port×1: support external 8Ω15W sub speakers
• Short circuit input port x 3
• Short circuit output port x 1
• • Max support : 30V/2A
  • Terminal socket
• Working humidity: 10~95%
• Storage temperature: -30℃~ 60℃
• Working temperature: -20℃~ 55℃
• LED: Blue, green, cyan, can be customized
• DC power input: DC 24V/2A
• Installation: Wall-mounted installation, universal bracket installation(optional)
• Color: Black
• Device overall dimensions: 184.85mm×275.38mm×124.56mm
• Gift box dimensions: 237mm×350mm×182m
• Outer CTN dimensions: 6578mm×375mm×500mm(6 PCS)
