Dinstar DAG1000-8S Technical Specifications
Physical Interfaces
- DAG1000-8S, 8 FXS, RJ11
- 1 X WAN, 10/100Mbps, RJ-45
- 2 X LAN, 10/100Mbps, RJ-45
FXS
- Connector: RJ11
- Reversed Polarity
- Max Cable Length: 3Km
- Pulse: 10 and 20 PPS
- Dial Mode: DTMF and Pulse
- Caller ID: DTMF/FSK CLI Presentation
- Programmable Call Progress Tone
Voice & FAX
- Codecs: G.711A/U law, G.723.1, G.729A/B, G.726, AMR, iLBC
- Silence Suppression
- Comfort Noise Generator(CNG)
- Voice Activity Detection(VAD)
- Echo Cancellation: G.168 with up to 128ms
- Adaptive (Dynamic) Jitter Buffer
- Hook Flash
- Programmable Gain Control
- T.38 Pass-through
- Modem/POS
- DTMF modes: SIP Info/RFC2833/Inband
- VLAN 802.1P/802.1Q (voice/data/management VLANs)
- Layer3 QoS and DiffServ
VoIP
- Protocol : SIP v2.0 (UDP/TCP),RFC3261, SDP,RTP(RFC2833), RFC3262, 3263,3264,3265,3515,2976,3311 ETC (3GPP TS24.629), RFC3891, RFC3892
- SIP TLS/SRTP
- RTP/RTCP, RFC2198, 1889
- RFC4028 Session Timer
- RFC3266 IPv6 in SDP
- RFC2806 TEL URI
- RFC3581 NAT,rport
- Primary/Backup SIP Server
- Outbound Proxy
- DNS SRV/ A Query/NATPR Query
- SIP Trunk
- Early Media/Early Answer
- NAT:STUN, Static/Dynamic NAT
Maintenance
- SNMP v1/v2/v3
- TR069, TR181
- Auto Provisioning
- Web/Telnet
- Configuration Backup/Restore
- Firmware Upgrade via Web
- CDR
- Syslog(Emerg,alert, critical,error warning,notice,info, debug)
- Ping/Tracert Test
- Network Capture
- Outward Test(GR909)
- NTP/Daylight Saving Time
- IVR local Maintenance
- Cloud-based Management
Software Features
- Hunting Group
- Web ACL
- Telnet ACL
- Action URL
- PPPoE/IPv4/IPv6
- Digitmap
- Routing Rules based Prefixes
- Caller/Called Number Manipulation
Environment
- Power Supply : 100-240VAC, 50-60 Hz@DC12V 2A
- Power Consumption: 18W(Typical)
- Operating Temperature: 0 ℃ ~ 45 ℃
- Storage Temperature: -20 ℃ ~80 ℃
- Humidity: 10%-90% Non-Condensing
- Dimensions (W/D/H): 242*152*40mm
- Unit Weight: : 1 kg
- Compliance: CE, FCC
