Yealink SIP-T58W With Camera - Smart Business IP Video Phone

Yealink SIP-T58W with Camera Smart Business IP VIdeo Phone

Technical Specifications

Audio Features

• HD voice: HD handset, HD speaker
• Hearing aid compatible (HAC) handset
• Acoustic Shield, Noise Proof
• Smart Noise Filtering
• Audio codec: Opus, G.722, PCMU (G.711A), PCMA (G.711μ), G.729, G.729A, G.729B, G.729AB, G.726, G.723.1, iLBC
• DTMF: In-band, Out-of-band (RFC 2833) and SIP INFO
• Full-duplex hands-free speakerphone with AEC
• VAD, CNG, AEC, PLC, AJB, AGC

Video Features

• Video codec: H.264 High Profile, H.264, VP8
• Video quality: 720P (1280x720)-30fps ( ≥ 512 kbps)
• Yealink CAM50 camera: - 5 mega-pixel - Plug and play - Adjustable - With privacy shutter and LED indicator - Vertical tilt angle adjustable: 47±3°
• Field of view (FOV): 75°±5°
• Self view (local video preview)

Display and Indicator

• LCD screen: - 7” 1024 x 600 capacitive adjustable touch screen - Vertical tilt angle adjustable: 48°
• 5 points multi-touch surface
• Screensaver and Wallpaper
• LED for call and message waiting indication
• Intuitive user interface with icons and soft keys
• Multilingual user interface
• Caller ID with name, number and photo

Androin Bundled Application

• File Manager/Email/Calendar/Camera/Gallery/Recorder/Calculator/Browser/Message
• Third Party Android Application Support

Phone Features

• Yealink's SDK (Software Development Kit)
• 16 SIP Accounts
• Call hold, call forward, call waiting, call transfer
• One-touch speed dial, hotline, mute, DND
• Group listening, emergency call
• Redial, call return, auto answer
• Direct Ip call without SIP proxy
• Ring tone select/import/delete
• Set date time manually or automatically
• Dial plan, action URL/URI
• RTCP-XR (RFC3611), VQ-RTCPR (RFC60350
• 3-party video conferencing
• 10-party audio/video mix conferencing (up to two video calls)
• Data import/export via bluetooth, email, etc.
• DoorPhone features : Preview, One-button open, Monitoring
• USB/Bluetooth connectivity to Yealink CP900/CP700 speakerphone, USB connectivity to Yealink UH36 headset
• Analog PSTN calls via CPN10
• Wireless Access Point (AP Mode)

Corded - Cordless Phone (via DECT dongle DD10K)

• Up to 4 DECT Cordless handsets
• Up to 4 concurrent call
• Support Yealink W73H/W53H/W56H/W59R/DD Phone/CP930W
• Slave Handset for Master Deskset

Feature Keys

• 27 one-touch DSS Keys
• 7 feature keys : hold, transfer, message, headset, mute, redial, speaker phone
• Volume control key
• Illuminated mute/headset/hands-free speakerphone key

Interface

• Dual-ports Gigabit Ethernet
• Power over Ethernet, (IEEE 802.3af), class 3
• Built-in Dual Wi-Fi : - Network Standard:IEEE802.11a/b/g/n - Frequency range: 2.4GHz/5.0GHz
• Built-in Bluetooth 4.2 for : - Bluetooth Handset BTH58 - Bluetooth headset - Pairing mobile devices - Simultaneous connection of one headset and one mobile phone
• 1 x USB 2.0 port (on the top of the phone) for Yealink CAM50 Camera
• 1 x USB port 2.0 (on the rear of the phone) for : - USB flash drive - USB headset - Color screen expansion modules - Wireless headset adapter EHS40
• 1 x Security lock port
• 1 x RJ9 (4P4C) handset port
• 1 x RJ9 (4P4C) headset port
• Support up to 3 color-screen expansion modules

Network and Security

• IPV4/IPV6
• SIP v1 (RVC2543), v2 (RFC3261)
• Call server redudnancy supported
• NAT traversal : STUN mode
• Proxy mode and peer-to-peer SIP link mode
• IP assignment : Static/DHCP
• HTTP/HTTPS web server
• Time and date Syncronization using SNTP
• UDP/TCP/DNS-SRV (RFC3263)
• QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
• SRTP
• Transport Layer Security (TLS 1.3)
• HTTPS Certificate Manager
• AES encryption for configuration file (AES256)
• Adb encryption authenticated
• Digest authentication using MD5/MD5-sess
• OpenVPN, IEEE802.1X, L2TP VPN
• WPA2/WPA3
• Secure boot
• GARP (Generic Attribute Registration Protocol)

Other Physical Features

• Color : Classical Grey
• Wall Mountable (OPTIONAL)
•  External Yealink AC Adapter (optional) : AC100~240V Input and DC 5V/2A Output
• USB output currency : 5V == 500mA
• Power Consumtion (PSU) : 2.5W~7.5W
• Power Consumtion (PoE) : 3.3W~9W
• Dimension (W*D*H*T) : 259.4mm*220mm*239mm*42.6mm
• Operating Humidity : 10~95%
• Operating Temperature : 0-40°C (+32~104°F)

Package Features

• Yealink SIP T58W with camera IP Phone)
• Handset - Wired handset with handset cord
• Ethernet Cable
• Stand
• Yealink CAM50 Camera
• Quick Start Guide
• Power Adapter
